Emissions Tier (EPA)
Tier 4
Engine Fuel
Diesel
Maximum Governed RPM
2,500 rpm
Horsepower
24.8 hp
Turbocharged Engine
Optional Horsepower
n/a
Operating Weight
5,666 lb
Weight Class
2.6 t
Travel Speed – High
2.8 mph
Travel Speed – Low
1.5 mph
Arm Digging Force
3,552 lbf
Bucket Digging Force
4,991 lbf
Rated Lift Capacity
1997 lb
Lift Radius
118 in
Boom Swing – Left
60°
Boom Swing – Right
60°
Maximum Dig Depth
8.5 ft
Max Dump Height
9.9 ft
Maximum Reach at Ground Level
14.9 ft
Fuel Tank
9.1 gal
Auxiliary Std Flow
12.5 gal/min
Auxiliary Pressure
2,610 psi
Length
170.4 in
Overall Length in Travel Position
170.4 in
Width
59.6 in
Height
94.9 in
Height with Operator Cab
94.9 in
